Electric Toys Test Solutions

LISUN’s electric toys test solutions are engineered to meet the stringent requirements of key international safety standards, providing comprehensive support for evaluating the safety and performance of electric toys. These standards include IEC 62115:2017, which outlines critical safety criteria for electric toys covering electrical, mechanical, and thermal aspects to prevent hazards like electric shock and fire; IS 15644:2006 and UL 696:2020, which set region-specific safety guidelines for electric toys in India and the United States respectively; ISO 8124-1:2022 and EN 71-1:2014, which focus on mechanical and physical safety to avoid risks from sharp edges, small parts, and instability; and ASTM F963:2023, a comprehensive U.S. standard encompassing mechanical, flammability, chemical, and labeling requirements. Together, these standards form a global framework to ensure electric toys are safe for children.

LISUN’s electric toys test solutions cover all essential test items specified in the aforementioned standards, supported by a full suite of professional testing equipment. This enables a wide range of evaluations, including electrical safety tests (such as electric strength under humid conditions, insulation resistance, and leakage current), mechanical and physical performance assessments (including impact, drop, torque, tension, and stability tests), flammability and heat resistance checks (like glow-wire, needle-flame, and ball pressure tests), chemical content analysis, and electromagnetic compatibility (EMC) tests (such as electrostatic discharge, radiated fields, and transient burst immunity). By offering end-to-end testing support, we assist manufacturers and laboratories in ensuring their electric toys comply with global safety standards, safeguarding children’s well-being during play.

Electr Toy Test Solution

Standard:

Part 1	IEC 62115:2017	Electric toys-Safety
Part 2	IS 15644:2006	Safety Of Electric Toys
Part 3	UL 696:2020	Electric toys-Safety
Part 4	ISO 8124-1:2022	Safety of toys-Part 1: Safety aspects related to mechanical and physical properties
Part 5	ASTM F963:2023	Standard Consumer Safety Specification for Toy Safety
Part 6	EN 71-1:2014	Safety of toys – Part 1: Mechanical and physical properties

Part 1 IEC 62115:2017 Electric toys-Safety

LISUN supplies the fully test solutions for the following IEC 62115:2017, please see the below excel table:

IEC 62115:2017 Clause and Subject	LISUN MODEL
10.2 Electric strength under humid conditions	GDJS-015B
11 Electric toys used in water, electric toys used with liquid and electric toys cleaned with liquid	JL-X
12.1 test Ehb of IEC 60068-2-75. the spring hammer test.	IK01-07
13.4.1 test probe 11 of IEC 61032	SMT-1150
13.4.1 test fingernail of Figure 7 of IEC 60335-1:2010	SMT-335F7
13.4.2 Drop Test	LS-B33
17 Clearances and creepage distances	CK-1
18.1 Resistance to heat–ball pressure test	ZBP-T
18.1 Resistance to heat–ball pressure test	GW-500
18.2 Resistance to fire–glow-wire test	ZRS-3H
19 Radiation and similar hazards	LS-IEC62115C19
Annex E Safety of electric toys incorporating optical radiation sources	LS-IEC62115C19
Annex B Needle-flame test	ZY-3
Annex D Electric toys with protective electronic circuits
D.2.2 Electrostatic discharge	ESD61000-2
D.2.3 Radiated fields	GTEM-2
D.2.4 Transient bursts	EFT61000-4
D.2.5 Voltage surges	SG61000-5
D.2.6 Injected current	RFCI61000-6
D.2.7 Voltage dips and interruptions	CSS61000-11

Part 2 IS 15644:2006 Safety Of Electric Toys

LISUN supplies the fully test solutions for the following IS 15644:2006, please see the below excel table:

IS 15644:2006 Clause and Subject	LISUN MODEL
11 Moisture resistance	GDJS-015B
13 Mechanical strength	IK01-07
18 Clearances and creepage distances	CK-1
19.1 Ball presure test	ZBP-T
19.1 Ball presure test	GW-500
19.2 glow wire test	ZRS-3H
20 Radiation, toxicity and similar hazards	LS-IEC62115C19
Annex B Needle-flame test	ZY-3
Annex B 15 Insulation resistance and dielectric strength	WB2681A

Part 3 UL 696:2020 Electric toys-Safety

LISUN supplies the fully test solutions for the following UL 696:2020, please see the below excel table:

UL 696:2020 Clause and Subject	LISUN MODEL
10 Coatings and Platings	EDX-2A
Figure 19.1	SMT-PA100A-UZ11
Figure 19.2	SMT-PA130A
Figure 19.3	SMT-PA140A
Figure 19.4	SMT-02T10
26 Leakage Current Test	WB2675D
27 Humidity Conditioning Test	GDJS-015B
30 Temperature Test	GDJS-015B
28.2 Drop test	DT-60KG
31/36 Dielectric Voltage-Withstand Test	WB2671B
34 Stability Test	LVD-100KG

Part 4 ISO 8124-1:2022 Safety of toys-Part 1: Safety aspects related to mechanical and physical properties

LISUN supplies the fully test solutions for the following ISO 8124-1:2022, please see the below excel table:

ISO 8124-1:2022 Clause and Subject	LISUN MODEL
5.12 Stability and overload tests	WDT-2
5.14 Impact test for toys that cover the face	LS-B33
5.18 Determination of temperature increases	WS-1
5.24.2 Drop test	DT-60KG

Part 5 ASTM F963:2023 Standard Consumer Safety Specification for Toy Safety

LISUN supplies the fully test solutions for the following ASTM F963:2023, please see the below excel table:

ASTM F963:2023 Clause and Subject	LISUN MODEL
4.2 Flammability	ZY-3
4.3.5 Heavy Elements	EDX-2A
4.15 Stability and Over-load Requirements	WDT-2
8.15 Test for Stability of Ride-on Toys or Toy Seats	WDT-2
4.25.9.4 flame rating of UL-94 V-0	HVR-LS
8.7.1 Drop Test	DT-60KG
8.10 Compression Test	LS-B08

Part 6 Safety of toys – Part 1: Mechanical and physical properties

LISUN supplies the fully test solutions for the following EN 71-1:2014, please see the below excel table:

EN 71-1:2014 Clause and Subject	LISUN MODEL
8.3 Torque test	CH338
8.4 Tension test	PULL-2000KG
8.5 Drop test	DT-60KG
8.6 Tip over test	LS-DDT1-B
8.7 Impact test	LS-B33
8.8 Compression test	LS-B08
