IEC 60335-1 Clause 20 | IEC 60601-1 Clause 9.4.2.1 Stability Test Bench

Product No: WDT-2

Specifications
Videos
Downloads
Applications
Standards

WDT-2 stability test bench is a professional device designed specifically for the stability testing of related electrical equipment. By adjusting the test angle through a tilting mechanism and rotating the table surface through a rotating mechanism, the test sample can be placed on the table surface to comprehensively assess the stability performance of the test object under different placement conditions, ensuring that the equipment has reliable stability performance in actual use scenarios.

Standards:

Standards No.	Standards Name
IEC 60335-1:2023	Household and similar electrical appliances – Safety – Part 1: General requirements
IEC 60601-1:2020	Medical electrical equipment – Part 1: General requirements for basic safety and essential performance
GB/T 4706.1-2024	家用和类似用途电器的安全第 1 部分：通用要求
GB 9706.1-2020	医用电气设备第 1 部分：基本安全和基本性能的通用要求

Specifications:

LISUN Models	WDT-2	WDT-2A	WDT-2B
Test Station	Single Station
Table Diameter	Ф600mm	Ф800mm	Ф1000mm
Angle Adjustment Range	0~30°（Adjustable）
Table Rotation Speed	1 rpm （Adjustable）
Carrying Capacity	80kg
Features	High-quality spray-coated steel plate with angle ruler to facilitate measuring the tilt angle

IEC 60335-1: 2020 Clause 20

Tags：WDT-2 , WDT-2A , WDT-2B
