For the CFL (Compact Fluorescent Lamp) design and manufactory, LISUN can supply a full quality control test solution.
Integrating Sphere and Spectroradiometer Test System is for CFL lighting measurement. CFL’s quality should be tested by checking its photometric, colorimetric and electrical parameters. According to CIE127-1997, IES LM-79-19 and IES LM-80, it recommends to using an array spectroradiometer with an integrating sphere to test SSL products.
• Colorimetric: Chromaticity coordinates, CCT, Color Ratio, Peak Wavelength, Half Bandwidth, Dominant Wavelength, Color Purity, CRI, CQS, TM-30 (Rf, Rg), Spectrum Test
• Photometric: Luminous Flux, Luminous Efficiency, Radiant Power, EEI, Energy Efficiency Class, Pupil Flux, Pupil Flux Efficiency, Pupil Factor, Cirtopic Flux, PAR and PPF (Only LMS-9000B/LMS-7000 can test PAR and PPF)
• Electrical: Voltage, Current, Power, Power Factor (Option: VF, IF, VR, IR), Harmonic (Only LS2010 can test harmonic)
• CFL optical maintenance test: Flux VS time, CCT VS time, CRI VS time, Power VS time, Power Factor VS time, Current VS time and Flux Efficiency VS time.
The LSRF-3 is equipped with Class A fast photometric probe, so the sampling speed is up to 100kHz. It fully meets the requirement of BASIC, Energy Star V2.1, IEC-Pst, CA CEC, ASSIST, CIE SVM, IEEE Std 1789 standards, etc
The Goniophotometer is used to test the intensity distribution curve in 3D and export IES or LDT file for the lighting software such as DiaLux. The Goniophotometric System is according to LM-79, LM-80, IEC and CIE Standards.
Luminous Intensity Data, Luminous Intensity Distribution, Zonal Luminous Flux, Luminaries Efficiency, Luminance Distribution, Coefficient Of Utilization, Luminance Limitation Curves Glare, Maximum Ratio of Distance to Height, Equal Illuminance Diagrams, Curves of Luminaires VS Lighting Area, Isocandela Diagrams, Efficient Luminescence Angle, EEI, UGR, etc.
EMI-9KB/EMI-9KA is the EMI Receiver system which are fully meets CISPRl6-1, GB17743, FCC, EN55015 and EN55022. It is used to test the LED driver, LED luminaires and other electronic products. Detection frequency range: 9kHz~300MHz (EMI-9KB) or 9kHz~30MHz (EMI-9KA).
The Surge Generator (Lightning Surge Generator) SG61000-5 is according to IEC/EN61000-4-5. LISUN supplies up to 30KV/15KA output.
The Electrical Safety Tester is according to GB4706.1, IEC/EN60335-1, UL60335, GB7000, IEC60598, GB4943, IEC60950 and GB9706.1. It can test for Withstand Voltage (AC/DC), Insulation Resistance (IR), Leakage Current (LLC), Ground Resistance (GR) and Power.
According to IEC60695-2-1, IEC60695-2-10~IEC60695-2-13 (GB/T5169.10-2006~GB/T5169.13-2006) ，UL 746A, IEC829, DIN695 and VDE0471 to do the Insulation Burning & Flammability test
When you buy the SKD to assembly the electronic ballast or CFL, you may need to test the quality of the electronic components.
