UL 817:2025 Cord Sets and Power-Supply Cords

UL 817:2025 (13th Edition) is the ANSI/UL safety standard for cord sets and power‑supply cords rated up to 600 V, used in non‑hazardous indoor locations per NFPA 70. It covers molded/assembled plugs, connectors, hospital‑grade devices, and cord restraints, excluding temporary outdoor and seasonal lighting cords. It mandates electrical, mechanical, and fire safety tests—such as dielectric withstand, insulation resistance, bending, pull, and flammability—to prevent shock, fire, and injury hazards.

This 2025 update strengthens critical safety requirements: plug housing materials upgraded to UL 94 V‑2 (V‑0 for >16 A devices), improved grounding pin durability (500 insertions), enhanced low‑temperature bending performance, and higher pull‑test loads at cord entries. It also boosts child safety features, aligns with latest NEC provisions, and adds stricter monitoring for sealed batteries and multi‑criteria sensor stability, prioritizing reduced false alarms, faster fire response, and long‑term reliability.

LISUN supplies the fully test solutions for the following UL 817:2025, please see the below excel table:

UL 817:2025 Clause and Subject	LISUN MODEL
6.2 Flammability	HVR-LS
6.4 Accessibility of live parts Figure 6.1	SMT-PA100A
11.2 Security of insulation test	WB2681A
11.5 Insulation resistance test	WB2681A
11.3.3 Investigation of strain relief clamps requiring supplementary mechanical protection	GW-500
	LS9923
11.3.5 Flatiron and appliance plugs Figure 11.1	LSPTT-1
11.4 Dielectric voltage-withstand test	LS9923
11.6 Accelerated aging test	GDJS-015B
11.12 Cycling heat test	GDJS-015B
11.7 Crushing test	LS-TCT-1
11.8 Impact resistance test	IK07-10
11.9 Flexing test	SW-6
11.13 Figure 11.6 Rain-Test Spray-Head Piping	JL-UL
17.6 Water exclusion test for enclosures of outdoor-use products Figure 17.1	JL-UL
12.2 Temperature test	WS-1
12.3 Plug grip test	LS-B18
14.10 Random drop test	DT-60KG
