14 Mar, 2023 643 Views Author: Cherry Shen

What is the waterproof grade of IPX34 Swing Pipe Water Spray Test Equipment

What is the waterproof grade of IPX34 Swing Pipe Water Spray Test Equipment:
IPX3 Swing Pipe Water Spray Test Equipment : spray holes are arranged in 60 ° arc sections on both sides of the midpoint of the pendulum tube; The tested shell is placed in the center of the semicircle of the pendulum tube, and the pendulum tube swings 60 ° along both sides of the vertical line. Each swing takes about 4S (2 × 120 °), the test duration is 5min; Then rotate the shell 90 ° in the horizontal direction, and then test for 5min; The allowable radius of swing pipe is 1600mm. During the test of some types of equipment, the shell cannot be completely wetted, and the shell support can be adjusted up and down.

video

IPX4 Swing Pipe Water Spray Test Equipment : spray holes are arranged in 180 ° arc sections on both sides of the midpoint of the pendulum tube; The tested shell is placed in the center of the semicircle of the pendulum tube, and the pendulum tube swings 180 ° along both sides of the vertical line, a total of 360 °; Each swing takes about 12S (2 × 180 °), the test duration is 10min; The tested shell support shall be perforated to avoid becoming a water baffle; Swing the swing tube to a certain limit in each direction, so that the shell will be splashed in all directions.

Solution to the problem of IPX34 Swing Pipe Water Spray Test Equipment :
IPX34 water spraying test machine, which uses imported servo motor, has relatively strong stability, and has not yet experienced out-of-step operation. It can set an angle of 0-350 ° in the rain swing on the touch screen. After the angle adjustment is completed, its electric eye sensor will automatically reset the swing tube. It is a box-type structure, water can be recycled, and the material used is 304 stainless steel, which is not easy to rust, can effectively resist various external environments, and meet the requirements of not easy to corrode for a long time.

After the customer bought our IPX34 water spraying testing machine, the quality is still relatively guaranteed, and there has been no abnormal operation of the instrument so far. Of course, we will also do the preparatory work in advance and regularly check it. When customers purchase products from our company, our company will have a relevant after-sales service to solve the abnormal problems of the equipment caused by various reasons during the use of the customer.

Therefore, when using IPX34 Swing Pipe Water Spray Test Equipment , there may be problems caused by operators, frequency of use, current environment and other factors. How can we minimize these problems? Here are some solutions to common problems for your reference.

1. IPX34 Swing Pipe Water Spray Test Equipment cannot be tested after it is started.
Cause: The angle of swing tube does not reach zero.
Solution: click the tube swing to zero in the operation interface.

2. The water flow of IPX34 water spraying tester cannot meet the standard detection parameters.
Cause: needle deformation or blockage
Solution: Replace deformed and blocked needles.
3. The pendulum tube of IPX34 pendulum tube rain tester has no water spray, or the water is very small.
Cause: The water tank has no water and the filter element in the filter is blocked
Solution: Turn on the water adding button and replace the filter element in the filter.

What should I do if the IPX34 Swing Pipe Water Spray Test Equipment is abnormal?
1. The pendulum tube rain test device cannot be started;
2. The pendulum rain test device cannot spray.
The above two abnormalities are relatively common faults. When the pendulum tube rain test device cannot be started, we need to check whether the power supply is plugged in or loosened, and also check whether other accessories operate normally. Therefore, the pendulum tube rain test device can not spray, generally because the nozzle is blocked, it is necessary to clean the nozzle of the pendulum tube rain test device, or replace the nozzle, and check whether there is foreign matter inside the water pipe. If you can’t do these checks, you can contact the relevant technical engineer for a repair.

LISUN lauched JL-X waterproof test machine is according to IEC60529:1989 +A1:1999 +A2:2013 《Degrees of protection provided by enclosures(IP Code)》IEC60598, IEC60335 and IEC 60034-5, GB/T-2423.2GB4208GB7000.1. The JL-X includes the following test grades: IPX1, IPX2, IPX3, IPX4, IPX5, IPX6, IPX7 and IPX8 (Refer to page 51 of IEC60529). It is widely used in the authentication test organization for the products such as electrical & electronic products, LED luminaires as well as in the relevant quality control department for the waterproof detection of the enclosures protection grades.

Swing Pipe Water Spray Test Equipment (JL-34): It is for IPX3 and IPX4 waterproof test. The semi-diameter of swing pipe is 1meter (Any other size is also available). The inside diameter of the swing pipe is 15mm. The sample rotating table diameter is 1000mm (Or other size according to the diameter of the swing pipe), and the height is adjustable. The rotation speed is 1~5rpm which controlled by PLC panel.

What is the waterproof grade of IPX34 Swing Pipe Water Spray Test Equipment

Waterproof Test Equipment JL-34

Lisun Instruments Limited was found by LISUN GROUP in 2003. LISUN quality system has been strictly certified by ISO9001:2015. As a CIE Membership, LISUN products are designed based on CIE, IEC and other international or national standards. All products passed CE certificate and authenticated by the third party lab.

Our main products are GoniophotometerIntegrating SphereSpectroradiometerSurge GeneratorESD Simulator GunsEMI ReceiverEMC Test EquipmentElectrical Safety TesterEnvironmental ChamberTemperature ChamberClimate ChamberThermal ChamberSalt Spray TestDust Test ChamberWaterproof TestRoHS Test (EDXRF)Glow Wire Test and Needle Flame Test.

Please feel free to contact us if you need any support.
Tech Dep: Service@Lisungroup.com, Cell/WhatsApp:+8615317907381
Sales Dep: Sales@Lisungroup.com, Cell/WhatsApp:+8618117273997
