UL 83 STANDARD FOR SAFETY – Thermoplastic-Insulated Wires and Cables

UL 83:2017 STANDARD FOR SAFETY – Thermoplastic – Insulated Wires and Cables specifies the requirements for 600V single – conductor thermoplastic – insulated wires and cables. It is applicable in Canada according to CSA C22.1, in Mexico according to NOM – 001 – SEDE, and in the United States according to ANSI/NFPA 70. This standard also covers submersible – pump cables, with or without jackets.

The standard details the cable structure, including requirements for conductors (made of copper, copper – clad aluminum or aluminum), insulation, and optional nylon sheaths. It specifies various test requirements, such as aluminum conductor elongation and tensile strength tests, insulation resistance tests in high – temperature water and long – term water, flexibility tests after aging, thermal shock tests, low – temperature bending tests, and flammability and smoke emission tests. There are also requirements for cable marking, which should include the manufacturer, model, conductor specification, etc., with a spacing of no more than 610mm.

LISUN supplies the fully test solutions for the following UL 83: 2017, please see the below excel table:

UL 83: 2017 Clause and Subject LISUN MODEL
5.9/7.4.4  Heat shock GDJS-015B
5.21 Long-term aging of insulation
5.10 Cold bend and cold impact HLST-500D
5.12 Flame and smoke HVR-LS
5.13 Weather (sunlight) resistance (optional) UV-263LS
5.18 Impact resistance IK01-06
5.24/7.4.3 Insulation resistance WB2681A
