EMI Test System | EMI Test Equipment

Product No: EMI-9KA

Leave a Message

=
  • Description
  • Video
  • Download
  • EMI-9KA is an automatic EMI test receiver or EMI Spectrum. It is a main test system for EMI (Electro Magnetic Interference) testing. The EMI-9KA EMI test equipment is produced by the full closure structure and strong electro-conductibility material, which has high shielding effect. Due to the new technology for the EMI Test System, it solved the instrument self-EMI problem. The test results are according to the international format test report.

    Standard:
    CISPR15:2018/ GB17743 “Limits and methods of measurement of radio disturbance characteristics of electrical lighting and similar equipment”
    CISPR16-1 “Specification for radio disturbance and immunity measuring apparatus and methods – Part 1-1: Radio disturbance and immunity measuring apparatus – Measuring apparatus”
    EN55015 “Limits and methods of measurement of radio disturbance characteristics of electrical lighting and similar equipment.”
    EN55022 “Radio disturbance characteristics – Limits and methods of measurement”

    Specification:
    • Detection frequency range: 9kHz~30MHz (EMI-9KA) or 9kHz~300MHz (EMI-9KB)
    • Frequency stability: 1×10-6
    • Frequency resolution: (9kHz~150kHz) 30Hz; (150kHz~30MHz) 1kHz
    • Test Tolerance: ±2 dB
    • Measure and Detection method: PK, QP and AV range from 20dBμV to 140dBμV
    • Test time: setting by customers
    • Frequency scanning step length: 20Hz~2MHz
    • Sweep bandwidth: 200Hz; 9kHz; 120kHz

    Jay Lee
    Jay Lee
    2019-11-09
    Jay Lee

    Free install and training service. High quality products, our boss was satisfied very much!

    Tags: ,
  • EMI-9KA EMI Test Receiver - Introduction Video

    vedio

    EMI-9KA EMI Test Receiver - Operation Video

    vedio
  • EMI-9KA EMI Test System Brochure CISPR15 2013 Standard Free Download CISPR15 2018 Standard Free Download CISPR16-1-AMD.2-F2-ED.1.0 1999 Standard Free Download EN55015 2000 Standard Free Download GB-17743 2007 Standard Free Download
