Product No: AGM-500
AGM-580/AGM-500 Gloss Meter uses Japanese sensors, American high-end op amp chips and processor chips to ensure test accuracy and achieve accurate measurement of material and surface gloss. Strictly follow domestic and international authoritative standards such as DIN 67530, ISO 2813, ASTM D 523, JIS Z8741, BS 3900 Part D5, etc. to ensure the standardization and universality of measurement data. The test accuracy meets the requirements of China’s JJG 696 first-level gloss meter standard and can be calibrated by iLac-MRA ISO17025 CNAS third party.
AGM-580/AGM-500 Gloss Meter is widely used in spraying, plastics, printing, metals, ceramics, building materials, leather, paint and other industries. In the field of spraying and painting, it monitors the gloss uniformity of the coating; the plastics industry helps to create an ideal surface gloss effect; the printing industry guarantees the color and gloss quality; the metal, ceramics, and building materials industries control the surface treatment process; the leather industry improves product quality to meet the production, R&D and quality inspection needs of various industries.
Specification:
LISUN Model | AGM-580 | AGM-500 | AGM-500PRO |
Product Names | Three-Angles Gloss Meter | Single-Angle Gloss Meter | |
Measuring Angles | 20°、60°、85° | 60° | |
Measuring Light Spot | 20°:10*10mm | N/A | |
60°:9*15mm | 60°:9*15mm | 60°:5*10mm | |
85°:5*38mm | N/A | ||
Measuring Range | 20°:0~2,000GU | N/A | |
60°:0~1,000GU | 60°:0~1,000GU | 60°:0~1,200GU | |
85°:0~160GU | N/A | ||
Graduation Value | 0~100: 0.1GU;>100: 1GU | ||
Measurement Mode | Simple mode, standard and sample measurement | N/A | |
Measurement Repeatability | 0~100GU: 0.2GU;100~2,000GU: 0.2%GU | 0.1 / 0.1% | |
Measurement Accuracy | Can be calibrated by iLac-MRA ISO17025 CNAS third party | N/A | |
Measuring Time | Less than 1s | ||
Data Storage | Can store 100 standard samples and 10,000 samples | N/A | |
Dimension(L*W*H) | 165*51*77mm | 84*70*17mm | |
Weight | 400g | 116g | |
Battery Level | 3,000mAh Lithium battery | 15,000 consecutive measurements on a single charge | |
Interface | USB、Bluetooth | USB、Bluetooth | |
Host computer software | including | N/A |
AGM-580/AGM-500 Gloss Meter Applications
