Electronic Ballast Production Line Tester

Product No: UI2000-OK

Leave a Message

=
  • Description
  • Electronic Ballast Production Line Tester Specifications:

    • Eight windows for displaying input characteristics, output characteristics, convenient for comparison and analysis.
    • Frequency response for testing input current up to 1 MHz, suitable for precise testing of various kind of electronic ballast.
    • High speed testing, finish testing input and output characteristics within 1 minute.
    • Portable with built-in chip micro-processor, particular suitable for development and spot production.
    • Parameters, waves and curves of input, output and startup can be printed.
    • Communicating with PC, special software provided and both Chinese version and English version available. Run in WINDOWS operation system, nice interface between people and computer, easy to operate.

    Technical parameters:
    1) Testing input parameters
    • Measuring voltage, current, power, power factor, power net frequency, total harmonic and 0-39 component of harmonic.
    • Printing data and curve
    • Range of basic wave frequency of voltage and current: 45Hz – 65Hz
    • Range of narrow band: 45Hz – 5 kHz
    • Range of broad band: 45Hz – 1MHz
    • Voltage range: 10 – 300V (virtual value)
    • Current range: 10mA – 2A (virtual value)
    • Power range: 0 – 600W
    • Power factor range: 0.000 – 1.000
    • Accuracy: 0.5 class
    2) Testing stable output parameters
    • Measuring lamp voltage, lamp current, lamp power, filament current, imported cathodic current, crest factor, oscillatory frequency.
    • Printing data and curve.
    • Range of lamp voltage: 10 – 250V
    • Range of lamp current, filament current, guided cathodic current: 10 – 800mA
    • Range of lamp power: 1 – 160W
    • Accuracy: 2 class
    3) Testing output parameters during start-up
    • Measuring pre-heating time, changing curve and data at the first 0-5 minutes of lamp voltage, lamp current, filament current, guided cathodic current, crest.
    • Range of lamp voltage: 10 – 800V
    • Range of lamp current, filament current, guided cathodic current: 10mA – 2A.
    • Accuracy: 2 class
