Test Probe 31 of IEC 61032 – Milling Grinding Probes

This IEC 61032 Figure 14 Test Probe 31 (milling grinding probe) is designed to check if hazardous mechanical parts in the grinding systems of food waste disposal units are inaccessible. It features a rigid metal rod with precise dimensions—including a 25mm diameter and 80mm working length—paired with two circular plates (60mm and 110mm diameters) to prevent over-insertion. Lightweight yet sturdy, it’s easy to maneuver during tests, ensuring reliable verification of mechanical safety. It aligns with global standards, making it a key tool for compliance checks on food waste disposers.

Specifications:
• Probe Type: IEC 61032 Figure 14 Test Probe 31 (milling grinding probe for food waste disposers)
• Rod Diameter: 25 mm ± 0.2 mm
• Rod Working Length: 80 mm ± 0.2 mm
• Front Plate Diameter: 60 mm ± 0.2 mm
• Back Plate Diameter: 110 mm ± 0.2 mm
• Total Probe Length: 150 mm ± 0.2 mm
• Material: High-strength metal (resists bending during insertion tests)
• Core Function: Verifies inaccessibility of hazardous mechanical parts in food waste disposer grinding systems
• Applied Force: No appreciable force (mimics accidental contact)
