IEC 80601-2-89 Figure 201.102e Ball Chain Loop and Spherical Mass
IEC 80601-2-89 Figure 201.102e Ball Chain Loop and Spherical Mass

IEC 80601-2-89 Figure 201.102e Ball Chain Loop and Spherical Mass

Product No: SMT-601F201103E

Leave a Message

=
  • Description

  • IEC 80601-2-89 Figure 201.102e Ball Chain Loop and Spherical Mass

    Key:
    1. Ball chain loop with a length of 200 ± 2 mm
    2. Spherical mass,weight 2.5 ± 0.05 kg and diameter 115± 1 mm
    3. Fixing point

    NOTE: The ball chain loopis formedby thebal chain entering thespherical mass at acommon fixing point.

    IEC 80601-2-89 Figure 201.102e Ball Chain Loop and Spherical Mass

    IEC 80601-2-89 Figure 201.102e Ball Chain Loop and Spherical Mass
