Articulate Probe of UL 2200 Figure 8.1

UL 2200 Figure 8.1 Articulate Probe.

Technical Parameter:

1. Knurled Finger Diameter: 12 mm
2. Knurled Finger Length: 80 mm
3. Baffle Plate Diameter: 50 mm
4. Baffle Plate Length: 100 mm
5. Baffle thickness: 20 mm

Standard:
UL 2200 “ANSI/CAN/UL/ULC Stationary Engine Generator Assemblies” Figure 8.1
