IEC 60754-1 Wire and Cable Thermal Shock Test Device

Product No: LS-B38

Leave a Message

=
  • Description

  • The LS-B38 Wire and Cable Thermal Shock Test Device is a specialized instrument for testing the thermal shock resistance performance of wires and cables. This equipment simulates specific thermal shock environments and, using specialized sample fixing, molding, and testing components, performs targeted tests on relevant wire and cable materials. It observes and judges whether cracks appear in the samples after testing, thereby evaluating the structural integrity and resistance performance of wires and cables under thermal shock conditions, ensuring that the tested products meet relevant technical specifications.

    Standard:

    Standards Standards Name
    GB/T 32129-2015 额定电压 450/750V 及以下无卤低烟阻燃电缆
    IEC 60754-1:2019 Test on gases evolved during combustion of materials from cables – Part 1: Determination of the halogen acid gas content

    Specification:

    Sample Dimensions Length: 127mm; Width: 6.0±0.1mm; Thickness: 3.0±0.1mm
    Test Rod Test rod: Diameter: 6mm, 4 pieces (length is round 300mm)
    Accessories 1 heavy-duty clamping head, 1 punching knife (127 mm × 6 mm)
    Test Stand 1 set
    Winding Stand 1 set
    Sample Fixture 1 set
    Material Bracket and clamp are made of stainless steel
    Weights 3sets of 2kg and 1set of 1kg
