Product No: WDT-B49
WDT-B49 Power Cord Wear Resistance Test Apparatus is used to test the abrasion resistance of finished flexible cables. The equipment simulates the wear scenarios of flexible cables during actual use through a specific sample fixing method and reciprocating motion design. It examines the abrasion resistance of the cable insulation layer through continuous mechanical action. After the test, voltage tests can be performed to verify the cable insulation integrity. The equipment supports simultaneous testing of multiple samples, is easy to operate, and the testing process is stable and controllable, providing accurate feedback on the cable’s abrasion resistance performance.
Standards:
| Standards | Standards Names |
| IEC 60245-1:2008 | Rubber insulated cables of rated voltage up to and including 450/750 V – Part 1: General requirements |
| IEC 60245-2:2008 | Rubber insulated cables of rated voltage up to and including 450/750 V – Part 2: Cables for fixed installations with copper conductors |
| GB/T 5013.1-2008 | 额定电压 450/750V 及以下橡皮绝缘电缆 第 1 部分：一般要求 |
| GB/T 5013.2-2008 | 额定电压 450/750V 及以下橡皮绝缘电缆 第 2 部分：固定敷设用电缆导体 |
Specification:
| Workstation | 3 workstations |
| Fixed Shaft Diameter | Φ40±0.3mm |
| Test Rate | One-way 40±1 times/min |
| Test Stroke | Move up and down within a distance of 0.1m |
| Weights | 500±5g, three pieces |
| Number of Trials | 0~999,999 times, can be set |
IEC 60245-1:2008 Clause 5.6.3.3
IEC 60245-2:1998 Clause 3.3
IEC 60245-2:2008 Figure 3
