UL 498 Figure 124.1 SB1276A Receptacle Test Fixture
UL 498 Figure 124.1 SB1276A Receptacle Test Fixture

REQUEST A QUOTE

=

UL 498 Figure 124.1 SB1276A Receptacle Test Fixture

Product No: GNGPL-SB1276A

  • Specifications
  • Standards
  • Tech Articles

  • Application:
    UL 498 Figure 124.1 SB1276A Receptacle Test Fixture is mainly used for testing and inspecting the structure and size of plugs and sockets to ensure conformity with UL 498:2017 standards. And the mainly application industries is electronics, electrical appliances, plugs and sockets and other similar areas.

    Feature:
    Gauge dimensions, tolerances, material, hardness, surface roughness conform to the standards requirements; Material hardness is more than 50HRC; Material thermal expansion coefficient is small,dimensions and tolerances is stable and reliable.

    Standard:
    UL 498 “Attachment Plugs and Receptacles” Figure 124.1

    UL 498 Figure 124.1 SB1276A Receptacle Test Fixture

    UL 498 Figure 124.1 SB1276A Receptacle Test Fixture
