NF C 61-314 CALIBRE C 3 POUR VÉRIFIER LA DISTANCE JUSQU’AU PREMIER POINT DE CONTACT

NF C 61-314 CALIBRE C 3 POUR VÉRIFIER LA DISTANCE JUSQU’AU PREMIER POINT DE CONTACT is designed in compliance with the NF C 61-314 standard, specializing in verifying the distance to the first point of contact for plugs and sockets. It serves as a critical testing tool for ensuring the safety and performance of electrical connection devices, with precise dimensional characteristics to meet the strict requirements of relevant electrical equipment testing and certification. It is an essential instrument for manufacturers, testing laboratories and quality inspection institutions engaged in the production and detection of plugs and sockets.

Specifications
• Complies with the NF C 61-314 standard
• Precisely calibrated to measure the distance to the first contact point of electrical connection components
• Features high-precision structural design for accurate testing results
• Has stable physical properties to ensure long-term testing reliability
• Adopts professional manufacturing processes to meet industrial testing accuracy demands

Test Procedures
• Prepare the plug or socket to be tested and ensure the surface of the tested product is clean and free of debris that may affect the test results.
• Take out the gauge and check its surface for damage or deformation to confirm it is in a usable state.
• Align the gauge with the corresponding contact part of the plug or socket according to the standard operation requirements.
• Slowly insert or fit the gauge into the tested position until the first contact point is reached, and record the measured distance data.
• Compare the measured data with the standard values specified in NF C 61-314 to judge whether the product meets the requirements.
• After the test is completed, clean the gauge and store it in a dry and dust-free environment to maintain its performance.

Applications
• Quality inspection of plug and socket products in electrical equipment manufacturing factories during the production process
• Certification testing of electrical connection devices in professional third-party testing laboratories
• Sampling inspection of plug and socket products in market supervision and quality inspection departments
• R&D and testing of new types of plug and socket products by electrical equipment R&D institutions to verify compliance with relevant standards
• Acceptance testing of incoming plug and socket components by enterprises that assemble electrical equipment
